单N-MOS

PE8124HM1 DFN3x3-8L

    PE8124HM1是VDS>12V,ID=24A，RDS(ON)<3.9m?，@VGS=4.5V，RDS(ON)<4.2m?，@VGS=3.8V，RDS(ON)<4.6m?，@VGS=3.0V，RDS(ON)<5.4m?，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.
    PE8124HM1的丝印是8124HM.PE8124HM1提供DFN3x3-8L封装.
    The PE8124HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
    PE8124HM1概述：
        PE8124HM1是VDS>12V,ID=24A，RDS(ON)<3.9m?，@VGS=4.5V，RDS(ON)<4.2m?，@VGS=3.8V，RDS(ON)<4.6m?，@VGS=3.0V，RDS(ON)<5.4m?，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE8124HM1的丝印是8124HM.PE8124HM1提供DFN3x3-8L封装.
        The PE8124HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.

    PE8124HM1特性：
    VDS > 12V, ID = 24A
    RDS(ON) < 3.9m? @ VGS=4.5V
    RDS(ON) < 4.2m? @VGS=3.8V
    RDS(ON) < 4.6m? @VGS=3.0V
    RDS(ON) < 5.4m? @VGS=2.5V
    ESD Rating: 4000V HBM
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8124HM1应用：
    PWM applications
    Load switch
    Power management

    PE8124HM1典型应用及引脚：

    请提交您的基本信息，发邮件Sales@ChipSourceTek.com,或者打电话给我们,13823761625(微信同号),我们将会尽快与您联系！

    *

    *

    *

    *
