PE8816是VDS=18V，ID=9A，RDS(ON)<10m? @VGS=4.5V，RDS(ON)<11m? @VGS=3.8V，RDS(ON)<13m? @VGS=2.5V的N沟道MOSFET。
PE8816的丝印是8816，PE8816提供SOT-23-6L封装。

The PE8816 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8816概述：

PE8816是VDS=18V，ID=9A，RDS(ON)<10m? @VGS=4.5V，RDS(ON)<11m? @VGS=3.8V，RDS(ON)<13m? @VGS=2.5V的N沟道MOSFET。PE8816的丝印是8816，PE8816提供SOT-23-6L封装。

The PE8816 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8816特性：

VDS = 18V, ID = 9A

RDS(ON) < 10m? @ VGS=4.5V

RDS(ON) < 11m? @VGS=3.8V

RDS(ON) < 13m? @VGS=2.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE8816应用：

Battery Protection

Load switch

Power management

PE8816典型应用及引脚：
