MXN2382概述：
    MXN2382是VDS=20V，ID=8A，@VGS=4.5V，RDS(ON)(Typ.)=10m?，@VGS=4.2V，RDS(ON)(Typ.)=11m?，@VGS=3.8V，RDS(ON)(Typ.)=11.5m?，@VGS=2.5V，RDS(ON)(Typ.)=15m?的Dual N-Channe MOSFET. MXN2382的丝印是NG25.MXN2382提供DFN2x3-6L封装.
    The MXN2382 uses advanced trench technology to provideexcellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as aload switch or in PWM applications. It is ESD protested..

MXN2382特性：
VDS =20V，ID =8A
@VGS=4.5V RDS(ON)(Typ.)=10m?
@VGS=4.2V RDS(ON)(Typ.)=11m?
@VGS=3.8V RDS(ON)(Typ.)=11.5m?
@VGS=2.5V RDS(ON)(Typ.)=15m?
ESD Rating:2000V HBM
High power and current handing capability
Lead free product is acquired
Surface mount package

MXN2382应用：
PWM applications
Load switch

MXN2382典型应用及引脚图：
