    The XYT2112-XX is low power consumption very low 2uA ground current, high performance 150mA LDO . The family uses an advanced CMOS process and a PMOSFET pass device to achieve fast start-up, with high output voltage accuracy . The XYT2112-XX is stable with a 10.0μF ceramic output capacitor, and uses a precision voltage reference and feedback loop to achieve a worst-case accuracy of 1% over all load, line, process, and temperature variations. It is fully specified from TJ =–40℃ to +125℃ and is offered in a SOT89-3 ，SOT23-3 package.

XYT2112 Features：

Wide Input Voltage Range: 2V to 30V

Up to 150mA Load Current

Very Low IQ: 2µA@Typ

High PSRR: 75dB@100Hz; 51dB@1KHz

Ultra Low Dropout: 650mV at 150mA Load @VOUT=5V

Short current protection:60mA

Excellent Load/Line Transient Response

Line Regulation: 0.05% typical

Package: SOT89-3，SOT23-3

XYT2112 Mark Specification Label：

Part No.		VOUT
XYT2112-3.0		3.0V
XYT2112-3.3		3.3V
XYT2112-5.0		5.0V

XYT2112 Application Circuits：
