    N+P-MOS

    PE4606 SOP8

        PE4606是N-Channel：VDS=30V,ID=6.5A，RDS(ON)<30m?，@VGS=10V，RDS(ON)<42m?，@VGS=4.5V.P-Channel:VDS=-30V,ID=-6A,RDS(ON)<33m?,@VGS=-10V,RDS(ON)<44m?,@VGS=-4.5V的N and P Channel Enhancement Mode Power MOSFET.
        PE4606的丝印是4606.PE4606提供SOP-8封装.
        The PE4606 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
      PE4606概述：
          PE4606是N-Channel：VDS=30V,ID=6.5A，RDS(ON)<30m?，@VGS=10V，RDS(ON)<42m?，@VGS=4.5V.P-Channel:VDS=-30V,ID=-6A,RDS(ON)<33m?,@VGS=-10V,RDS(ON)<44m?,@VGS=-4.5V的N and P Channel Enhancement Mode Power MOSFET.
          PE4606的丝印是4606.PE4606提供SOP-8封装.
          The PE4606 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

      PE4606特性：
      N-Channel
      VDS = 30V, ID = 6.5A
      RDS(ON) < 30m? @ VGS=10V
      RDS(ON) < 42m? @VGS=4.5V
      P-Channel
      VDS = -30V, ID = -6A
      RDS(ON) < 33m? @ VGS=-10V
      RDS(ON) < 44m?@VGS=-4.5V
      High Power and current handing capability
      Lead free product is acquired
      Surface Mount Package

      PE4606应用：
      PWM applications
      DC motor

      PE4606典型应用及引脚：

      请提交您的基本信息，发邮件Sales@ChipSourceTek.com,或者打电话给我们,13823761625(微信同号),我们将会尽快与您联系！

      *

      *

      *

      *
