    单N-MOS

    PE3400A SOT23

        PE3400A是VDS=30V,ID=5.8A，RDS(ON)<35m?，@VGS=10V，RDS(ON)<40m?，@VGS=4.5V，RDS(ON)<55m?，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.
        PE3400A的丝印是f.NC.PE3400A提供SOT-23封装.
       The PE3400A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
      PE3400A概述：
          PE3400A是VDS=30V,ID=5.8A，RDS(ON)<35m?，@VGS=10V，RDS(ON)<40m?，@VGS=4.5V，RDS(ON)<55m?，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE3400A的丝印是f.NC.PE3400A提供SOT-23封装.
          The PE3400A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

      PE3400A特性：
      VDS = 30V, ID = 5.8A
      RDS(ON) < 35m?@ VGS=10V
      RDS(ON) < 40m? @VGS=4.5V
      RDS(ON) < 55m?@VGS=2.5V
      High Power and current handing capability
      Lead free product is acquired
      Surface Mount Package

      PE3400A应用：
      PWM applications
      Load switch
      Power management

      PE3400A典型应用及引脚：
