PE2305概述：
    PE2305是VDS=-20V,ID=-4.5A，RDS(ON)<45m?，@VGS=-4.5V，RDS(ON)<60m?，@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET.
    PE2305提供SOT-23-3L封装.
    The PE2305 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2305特性：
VDS = -20V, ID = -4.5A
RDS(ON) < 45m? @VGS=-4.5V
RDS(ON) < 60m? @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2305应用：
PWM applications
Load switch
Power management

PE2305典型应用及引脚：
