MX2312A概述：
    MX2312A是VDS=20V,ID=4.5A,RDS(ON)(Typ.)=21mΩ,@VGS=2.5V,RDS(ON)(Typ.)=18mΩ,@VGS=4.5V的N沟道MOSFET.MX2312A提供SOT23封装.
    The MX2312A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a battery protection or in other switching application.

MX2312A特性：
VDS=20V, ID=4.5A
RDS(ON)(Typ.)=21mΩ @ VGS=2.5V
RDS(ON)(Typ.)=18mΩ @ VGS=4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

MX2312A应用:
Battery protection
Load switch
Power management

MX2312A订购信息：

MX2312A典型应用及封装图：
