JMTK10N10A概述:
JMTK10N10A特性：
JMTK10N10A是N沟道增强型功率MOSFET，
JMTK10N10A是100V,10A的N沟MOSFET/RDS(ON) <110mΩ @ VGS = 10V RDS(ON) <140mΩ @ VGS = 4.5V/JMTK10N10A丝印K10N10A
JMTQ025N02提供TO-252封装，JMTK10N10A丝印：K10N10A
JMTK10N10A是100V,10A的N沟MOSFET/RDS(ON) <110mΩ @ VGS = 10V RDS(ON) <140mΩ @ VGS = 4.5V/JMTK10N10A丝印K10N10A
JMTQ025N02提供TO-252封装，JMTK10N10A丝印：K10N10A
JMTK10N10A特性：
100V, 10A
RDS(ON) <110mΩ @ VGS = 10V
RDS(ON) <140mΩ @ VGS = 4.5V
Advanced Trench Technology
Provide Excellent RDS(ON) and Low Gate Charge
Lead free product is acquired
JMTK10N10A丝�。篕10N10A
JMTK10N10A丝�。篕10N10A
JMTK10N10A提供TO-252封装
JMTK10N10A应用:
Load Switch
PWM Application
Power management
订购信息：
订购信息：
|
Device Marking
|
Device
|
OUTLINE
|
evice Package
|
Reel Size
|
Reel
(PCS)
|
Per Carton
(PCS)
|
|
JMTK10N10A
|
JMTK10N10A
|
TAPING
|
TO-252
|
13inch
|
2500
|
25000
|
JMTK10N10A典型应用电路图:
