CST1005 Description/概述：
The CST1005 is the high cell density trenched N-ch MOSFETs, which provides excellent RDSON and efficiency for most of the small power switching and load switch applications.
The CST1005 meet the RoHS and Green Product requirement with full function reliability approved.
CST1005是BVDSS=100V,RDSON=95mΩ,ID=5.0A的N通道快速切换Mosfets。提供SOT23-3L封装。
CST1005 Features/特性：
Green Device Available
Super Low Gate Charge
Excellent Cdv/dt effect decline
Advanced high cell density Trench technology
CST1005 Product Summary:
|
BVDSS
|
RDSON
|
ID
|
|
100V
|
95mΩ
|
5.0 A
|
CST1005 SOT23-3L Pin Configuration:
