PE8706是VDS=18V，ID=8A，RDS(ON)<12m? @VGS=4.5V，RDS(ON)<13m? @VGS=3.8V，RDS(ON)<16m? @VGS=2.5V的N沟MOSFET。
PE8706的丝印是8706，PE8706提供SOT-23-6L封装。

The PE8706 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8706概述：

PE8706是VDS=18V，ID=8A，RDS(ON)<12m? @VGS=4.5V，RDS(ON)<13m? @VGS=3.8V，RDS(ON)<16m? @VGS=2.5V的N沟MOSFET。
PE8706的丝印是8706，PE8706提供SOT-23-6L封装。

The PE8706 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8706特性：

VDS = 18V, ID = 8A

RDS(ON) < 12m? @ VGS=4.5V

RDS(ON) < 13m? @VGS=3.8V

RDS(ON) < 16m? @VGS=2.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE8706应用：

Battery Protection

Load switch

Power management

PE8706典型应用及引脚：
