PE3415A是VDS=-20V,ID=-5A，RDS(ON)<40m?，@VGS=-4.5V，RDS(ON)<60m?，@VGS=-2.5V的P-Channel MOSFET.
PE3415A的丝印是3415E.PE3415A提供SOT-23封装.

The PE3415A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3415A概述：

PE3415A是VDS=-20V,ID=-5A，RDS(ON)<40m?，@VGS=-4.5V，RDS(ON)<60m?，@VGS=-2.5V的P-Channel MOSFET.PE3415A的丝印是3415E.PE3415A提供SOT-23封装.

The PE3415A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3415A特性：

VDS = -20V, ID = -5A

RDS(ON) < 40m? @VGS=-4.5V

RDS(ON) < 60m? @VGS=-2.5V

EAS Rating: ≥4000V HBM

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE3415A应用：

PWM applications

Load switch

Power management

PE3415A典型应用及引脚：
