PE4953是VDS=-30V,ID=-5.3A，RDS(ON)<49mΩ，@VGS=-10V，RDS(ON)<85mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
PE4953的丝印是PE4953.PE4953提供SOP-8封装.

The PE4953 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE4953概述：

PE4953是VDS=-30V,ID=-5.3A，RDS(ON)<49mΩ，@VGS=-10V，RDS(ON)<85mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE4953的丝印是PE4953.PE4953提供SOP-8封装.

The PE4953 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE4953特性：

VDS = -30V, ID = -5.3A

RDS(ON) < 49mΩ @ VGS=-10V

RDS(ON) < 85mΩ @VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE4953应用：

PWM applications

Load switch

Power management

PE4953典型应用及引脚图：
