MX30P15概述:
MX30P15是-30V,-15A的P沟道增强型功率MOSFET，
MX30P15丝印：30P15,MX30P15提供SOP8封装，VDS =-30V，ID=-15A,RDS(ON)(Typ.)8.5m?@VGS=-10V,RDS(ON)(Typ.)11.5m?@VGS=-4.5V,
The MX30P15 uses advanced trench technology to provide excellent RDS(ON), This device is suitable for use as a load switch or in PWM applicatinos.
MX30P15丝印：30P15,MX30P15提供SOP8封装，VDS =-30V，ID=-15A,RDS(ON)(Typ.)8.5m?@VGS=-10V,RDS(ON)(Typ.)11.5m?@VGS=-4.5V,
The MX30P15 uses advanced trench technology to provide excellent RDS(ON), This device is suitable for use as a load switch or in PWM applicatinos.
MX30P15特性：
VDS =-30V，ID=-15A
RDS(ON)(Typ.)8.5m?@VGS=-10V
RDS(ON)(Typ.)11.5m?@VGS=-4.5V
High Power and current handing capability
Lead free product is acquired
Surface mount package
MX30P15丝�。�30P15
MX30P15提供SOP8封装
MX30P15应用：
PWM applications
Load switch
Power
MX30P15典型应用电路图：
