MX8205AH概述：
    MX8205AH是VDS=20V,ID=6A，RDS(ON)(Typ.)=22mΩ，@VGS=4.5V，RDS(ON)(Typ.)=27mΩ，@VGS=2.5V的N-Channel MOSFET.MX8205AH提供SOT23-6封装.
    The MX8205AH uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a Battery protection or in other Switching applications.

MX8205AH特性：
VDS = 20V,ID =6A
RDS(ON) (Typ.) =22mΩ @ VGS=4.5V
RDS(ON)(Typ.) =27mΩ @ VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

MX8205AH应用：
Battery protection
Load switch
Power management

MX8205AH典型应用及引脚图：
