JMTK50N06B是VDS=60V,ID=50A, RDS(ON)<17mΩ@VGS=10V,RDS(ON)<25mΩ@VGS=4.5V的N沟道MOS.
JMTK50N06B的丝印是K50N06B.
JMTK50N06B提供TO252封装.

JMTK50N06B概述：

JMTK50N06B是VDS=60V,ID=50A, RDS(ON)<17mΩ@VGS=10V,RDS(ON)<25mΩ@VGS=4.5V的N沟道MOS.
JMTK50N06B的丝印是K50N06B.JMTK50N06B提供TO252封装。

JMTK50N06B特性：

60V,50A

RDS(ON) <17mΩ @ VGS = 10V

RDS(ON) <25mΩ @ VGS = 4.5V

Advanced Trench Technology

Provide Excellent RDS(ON) and Low Gate Charge

Lead free product is acquired

JMTK50N06B提供TO252封装

JMTK50N06B应用市�。�

Load Switch

PWM Application

Power management

订购信息：

Device Marking	Device	OUTLINE	evice Package	Reel Size	Reel (PCS)	Per Carton (PCS)
JMTK50N06B	JMTK50N06B	TAPING	TO-252	13inch	2500	25000

JMTK50N06B应用图：
