PE2301A概述：

    PE2301A是VDS=-20V,ID=-3A,RDS(ON)<110m?,@VGS=-4.5V,RDS(ON)<140m?,@VGS=-2.5V的P-Channel MOSFET.
    PE2301A的丝印是a.NC3A.PE2301A提供SOT-23封装.
    The PE2301A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2301A特性：
VDS = -20V, ID = -3A
RDS(ON) < 110m? @VGS=-4.5V
RDS(ON) < 140m? @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2301A应用：
PWM applications
Load switch
Power management

PE2301A典型应用及引脚图：
