MX2301A概述
    MX2301A是P沟道的MOSFET，丝印是a.NC3A,提供SOT-23封装。
    The MX2301A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 1.8V.
    This device is suitable for use as a load switch or in PWM applications.

MX2301A特性
VDS =-20V，ID =-3A
@VGS=-2.5V RDS(ON)(Typ.)=110m?
@VGS=-4.5V RDS(ON)(Typ.)=85m?
High power and current handing capability
Lead free product is acquired
Surface mount package

MX2301A应用
PWM applications
Load switch

MX2301A典型应用及封装图
